AT6550 Medium size high resolution security X-ray scanner for hotel shopping malls train metro stations(Cargo X Ray Inspection)
Application: Train Metro Station; Jail House; Embassy; Boarder check points; Office buildings; Shopping malls etc Features: 140KV generator; Dual-energy X-ray Imaging;
Модель:
Product description
Medium size high resolution security X-ray scanner for hotel shopping mall Model AT6550
Suitable for security inspection of briefcase, hand luggage, postal parcels and other small packages.
Technical characteristics
* Dural energy penetration system;
* TIP program;
* Clear and distinct image;
* Scanned imaged can zoom up to 64 times;
High Light
* Powerful image dealing ability;
* XP operation system；
* Automatic save scanned image;
* Friendly operation System;
* Reliable performance.
* Explosives & narcotics alarm and highlight according to atomic number signature
General Specification:
Tunnel Size: 650mm×500mm
Conveyor Speed: 0.22m/s
Conveyor height: 695mm
Conveyor Max Load:170kg
X ray Dose per inspection <1.14μSv
Wire Resolution: 40 AWG typical
Spatial resolution Level: dia1.0mm,Vertical: dia1.0mm
Penetration: 30 mm steel guarantee, 32mm steel typical
Penetration Resolution: 30AWG ,the wire visible below 15.9mm thick aluminum
Film Safety: Guarantee ASA/ISO1600 Film
X-ray Leakage: <0.5 μSv/h (at a distance of 5cm From external housing)
Operating Environment:
Operation temperature/Humidity: 5℃-40℃/10%-95%(non-condensing)
Storage Temperature/Humidity: -20℃to 60℃/ 5%-95%(non-condensing)
Operation Power: 220VAC(±10%)50±3Hz (Optional: 100VAC,110VAC,120VAC,200VAC)
Power Consumption: 1.0KW (max), 0.7KW(working)
Noise: <58db
Dimensions (L×W×H): 2195mm x902mm x1362mm
Device Weight: 465Kg
G.Weight: 700Kg
Packing Volume: 5.54CBM
Computer Character:
CASE: IPC7132
Power: 250W/ATX
Main board: AIMB 501G2
CPU: G1610 2.6G
Storage: 2GB 1600MHz DDR3 Innodisk
Hard Disk: SEAGATE 500G 3.5”
X-ray Generator:
Anode Voltage: 140kv
Anode power: 0.35mA
Generate angle: 80 degree upward
Brand: SECUSCAN ( own made )
Generate direct: from top to bottom
Cooling / Duty Cycle: Oil Cooling /100%
Other characters:
Detect PCB board: UK brand Sensortech
Extension Rollers: customize size length
Support card reader operator access
CD DVR/RW unit: Optional
Computer system: XP system
Monitor: 17 inch monitor
